M&H Laser Tool Setter 35.20

The tool setter m&h TS35.20 is designed for use on milling and machining centres and is used to determine tool geometries. The precision measuring mechanism reliably measures tool lengths and tool radii, as well as individual cutting edges and detects tool breakage. The measurement can be both static and dynamic.

• Measurements in X-,Y- and Z-direction
• Compact design
• Sturdy and absolutely waterproof
• Simple alignment of the measuring surface
